60V / 5A Slim SMPS DC Regulated Power Supply (300W)

About.

The Vartech 6005 S is a slim, lightweight SMPS-based DC regulated power supply rated at 0–60 V, 0–5 A (300 W). In the same compact 73 × 140 × 205 mm chassis as the 3005 S and 3010 S, it delivers up to 60 V output - useful for higher-voltage bench testing where a lightweight supply is required. Adjustable OVP (up to 74.4 V), OCP and OPP, panel lock, beeper, output On/Off and preset V/I are all included.

• 0–60 V, 0–5 A, 300 W rated output
• Slim design - 73 × 140 × 205 mm, ~1 kg
• SMPS post-stage voltage regulation - efficiency > 85 %
• Auto CV / CC switching | Coarse & Fine controls
• Adjustable OVP (up to 74.4 V), OCP and OPP | OTP protection
• Panel lock | Beeper alarm | Output On/Off
• Preset voltage and current when output is OFF

Specifications.

Rated Output

60 V, 5 A

Rated Power

300 W

Max Display

62 V, 5.1 A

OVP Range

0.1 V–74.4 V

OCP Range

0.01 A–5.61 A

OPP Range

0.1 W–347 W

Line Regulation

CV ≤ 0.2 % of rated voltage | CC ≤ 0.2 % of rated current

Load Regulation

CV ≤ 0.2 % of rated voltage | CC ≤ 0.2 % of rated current

Ripple & Noise

CV ≤ 0.5 % FS rms | CC ≤ 0.5 % FS rms

Efficiency

> 85 %

Display

3-digit LED (V, A, W)

Display Resolution

Voltage: 0.1 V | Current: 0.01 A | Power: 0.01 W – 0.1 W – 1 W (auto)

Display Accuracy

± (0.1 % reading + 1 digit)

Readback Accuracy

± (0.2 % reading + 1 digit)
