Digital Insulation Tester - up to 5000 V / 200 GΩ

About.

The DIT-5000 is a dedicated digital insulation tester testing insulation resistance at voltages up to 5000 V, with resistance measurement up to 200 GΩ. Auto-range operation, automatic zero calibration, and automatic polarity display simplify field use. A high-voltage LED indicator warns the operator when the output is live. Results are shown on a 3½-digit LCD (68 × 55 mm, 35 mm character height) with backlight. Also includes AC voltage measurement up to 750 V (secondary function - not a full multimeter). Powered by 6 × 1.5 V AA batteries (replaceable, not rechargeable). Accuracy is tiered by resistance range (see specifications). Dimensions: 218 × 122 × 75 mm. Weight: approx. 900 g. Supplied with test leads, batteries, user manual, and carrying box.

• Insulation testing of motors and rotating machines at higher test voltages
• HV transformer and cable insulation testing up to 5000 V
• Utilities and large industrial plants requiring 5000 V class insulation testing

Specifications.

Output Voltage

500 V / 1000 V / 2500 V / 5000 V

Insulation Resistance

1 MΩ – 200 GΩ

Short Circuit Current

1 mA

AC Voltage Measurement

Up to 750 V (secondary function)

Display

3½-digit LCD, 68 × 55 mm (35 mm character height), with backlight

Ranging

Auto-range with auto zero calibration and auto polarity display

HV Indicator

High-voltage LED - illuminates when output is active

Accuracy (1 MΩ–200 MΩ)

±(3% × reading + 5 digits)

Accuracy (200 MΩ–10 GΩ)

±(5% × reading + 5 digits)

Accuracy (10 GΩ–200 GΩ)

±(10% × reading + 5 digits)

Power Supply

6 × 1.5 V AA batteries (replaceable - not rechargeable)

Dimensions (L×W×H)

218 × 122 × 75 mm

Weight

Approx. 900 g

Warranty

12 months against manufacturing defects only
